Next Generation Autonomous USV
Performs In Environments & Conditions Where Other Manned And Unmanned Systems Cannot.
![](https://static.wixstatic.com/media/752ed1_3087c8355d9849fea77fccde86d18ba7~mv2.jpg/v1/fill/w_147,h_76,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/752ed1_3087c8355d9849fea77fccde86d18ba7~mv2.jpg)
Single man portable above surface ISR system
Integration examples:
· E/O Camera kits
· SIGInt kits
· LOS, BLOS, 4GLTE, Satcom commskits
Missions:
· ISR, SIGInt, quick interceptdetection
· Can be deployed from larger USVs to form swarms
· Near-shore, inland waters system
More Information: https://www.esc.guide/martac
Specifications
Length / Width / Height: 2.0 m / 0.53 m / 0.25m
Draft: 0.15m
Maximum Vessel Weight: 36 kg
Maximum Payload Weight: 7 kg(Max payload weight may be exceeded but at significant performance degradation)
PropulsionType: Twin Screw Electric Surface Drive
Operation Speed (kts): 0 - 15
Max Speed (kts): 50
Range (nm): 15 -35
Endurance (hrs) at Cruise (@ 10 kts): 1,5 - 2,5
Time on station (hours/days): 12 hours
Sea State Capable/ Survivable: 2/5
Self-righting Capable: No
Gator Capable: No
Weapons Types: ISR, Electronic Warfare, C4 WIED (Water-born Incendiary Explosive Device - surface torpedo) NOTE: This capability is not integrated by MARTAC and would need to be integrated through a 3rd party supplier or the country end-user.
